Screw Juice Extractor Machine



Screw Juice Extractor Machine consists of a front support, a feed hopper, a screw shaft, a filter screen,a juice container, a rear support, a slag chute and other components. The left end of the

screw spindle is supported in a rolling bearing seat, and the right end is supported in a hand wheel bearing seat. The motor drives the screw shaft to operate through a pair of belt pulleys.





1. Screw Juice Extractor Machine is made of 304 stainless steel , which is very health and safe.

2. Screw Juice Extractor Machine is widely used for kinds of fruits and vegetables, such as the carrot, celery, spinach, tomatoes, pineapple, pear, apple, orange and so on. It is widely used in the fruit processing industry, food and beverage processing factory.

working principle: The spiral shaft rotates clockwise along the direction of the slag outlet,

the bottom diameter .gradually increases and the pitch gradually decreases. When the material

is pushed by the spiral shaft, the spiral cavity gradually decreases, thus forming the squeezing

of the material.





1. Robust design: Screw Juice Extractor Machines have a sturdy built that can withstand the rigorous pressure during the juice extraction process.

2. High yield juice extractor: Screw Juice Extractor Machines offer a high yield of juice, almost double that of traditional extractors.

3. Automatic cleaning system: The machine has an automatic cleaning system that saves you time and effort after the juice extraction process.

4. Versatility: With a screw juice extractor machine, you can extract juice from various types of fruits and vegetables, including apples, pears, carrots, beets, spinach, and celery, among others.

5. Large capacity: Screw Juice Extractor Machines come in different sizes to serve both home use and commercial operations.

6. Safety: The machines have safety features that prevent accidents, including electric shock and overheating.

7.Noiseless operation: Screw Juice Extractor Machines operate silently, making them ideal for home use where noise may be a disturbance.





Operating a screw juice machine is relatively easy and straightforward. Here are the steps to follow:

1. Wash the fruits and vegetables you intend to juice thoroughly, removing any dirt or debris.

2. Cut the produce into small pieces that will easily fit into the extraction chamber of the machine.

3. Set up the screw juice machine by fixing the juice container onto the designated area.

4. Turn the machine on and feed the fruits and vegetables into the feeding tube.

5. Allow the machine to crush and extract the juice from the fruits and vegetables.

6. Collect the juice in the container as it comes out of the machine.

7.Once the extraction process is complete, switch off the machine and clean it thoroughly.





After sales service is an essential aspect of any product, and spiral juice machines are no exception. When purchasing a screw juicer, please ensure that the manufacturer or retailer provides sufficient support in case of technical issues, warranty, and parts replacement.

We provide a warranty period for our juicer and support customers in the event of any issues. Customer support includes troubleshooting tips, repair services, and replacement parts. We have a good performance record in the industry, ensuring high-quality after-sales service.

In short, spiral juice machines have the advantages of high yield, high juice quality, and simple operation. Ensure that you choose the size and design that suits your needs and budget. Through appropriate maintenance and after-sales service, the spiral juice machine can be used for several years and provide you with healthy and nutritious juice when you need it.





Model	HT-LZ0.5	HT-LZ1	HT-LZ1.5	HT-LZ2.5	HT-LZ5
capacity	0.5 T/H	1T/H	1.5 T/H	2.5 T/H	5 T/H
Spiral diameter	φ88mm	φ125	φ175	φ250mm	φ400mm
Stainer aperture	φ0.6mm	φ0.6mm	φ0.5mm	φ0.6mm	φ0.6mm
Motor power	1.5 KW	2.2KW	4KW	15KW	30KW
weight	85KG	114KG	240KG	440KG	1300KG
Dimension	780×320×860mm	880×330×900mm	1300×700×1300mm	1540×700×1300mm	2530×944×1870mm
