Electric Jacketed Kettle
2. Manual worm gear transmission is used to tilt the machine and discharge the material.
3. It is mostly used in large restaurants or canteens to cook soup, vegetables, stew, porridge, etc. to improve working conditions
Introduction to Electric Jacketed Kettle
The Electric Jacketed Kettle uses a 380V power source as the heat source, and is equipped with an electric heating rod, thermocouple, and thermal oil (self-made) inside, with a temperature of up to 320 degrees. It is controlled by an electric control box and equipped with an automatic temperature control system. Large heating area, uniform heating, short liquid boiling time, and easy control of heating temperature.
The Electric Jacketed Kettle adopts manual worm gear transmission, with a simple structure, small volume, and convenient operation. The pot body can be roughly tilted to completely pour out the liquid feed. Due to the use of indirect heating (heating medium can be hot water or steam), the constant temperature heating effect of the material can be achieved.
The application of Electric Jacketed Kettle
Electric Jacketed Kettle are commonly used in the food processing industry for cooking, mixing, heating, and cooling various foods. A Electric Jacketed Kettle is used for cooking sauces and gravy; Make stews, soups, and chili peppers; Cooking vegetables and pasta; And prepare large-scale batter, gravy, and pork. This machine can also be used for heating, cooling, and mixing compounds in the pharmaceutical and chemical industries.
This Electric Jacketed Kettle is designed for heating and cooking various substances, including liquids, solids, and semi-solids. The Electric Jacketed Kettle mainly consists of a pot body and supporting legs; The pot body is a double-layer structure composed of an inner and outer spherical pot body, with the middle layer filled with thermal oil or hot water.
technical parameter
|
Model |
HT-JCG50 |
HT-JCG100 |
HT-JCG200 |
HT-JCG300 |
|
Electric Heating Size(mm) |
1300*850*950 |
1000*1500*850 |
1600*950*1050 |
1650*1000*1050 |
|
Gas Heating Size(mm) |
1450*1000*1050 |
1050*1200*860 |
1600*960*1300 |
1400*1160*1200 |
|
Steam Size(mm) |
1300*850*950 |
1000*1500*850 |
1600*950*1050 |
1650*1000*1050 |
|
Volume(m³ ) |
0.05 |
0.1 |
0.2 |
0.3 |
|
Electric Heating Tube Power |
9kw |
15kw |
12-15kw |
15-18kw |
|
Overall Weight (kg) |
150kg |
185kg |
220kg |
260kg |
|
Model |
HT-JCG400 |
HT-JCG500 |
HT-JCG600 |
HT-JCG800 |
|
Electric Heating Size(mm) |
1650*1200*1250 |
1700*1100*1150 |
1750*1250*1250 |
1850*1350*1500 |
|
Gas Heating Size(mm) |
1550*1200*1250 |
1700*1300*1150 |
1850*1400*1350 |
2010*1400*1600 |
|
Steam Size(mm) |
1650*1200*1250 |
1700*1100*1150 |
1750*1250*1250 |
1850*1350*1500 |
|
Volume(m³ ) |
0.05 |
0.1 |
0.2 |
0.3 |
|
Electric Heating Tube Power |
18-24kw |
18-27kw |
24-36kw |
24-36kw |
|
Overall Weight (kg) |
300kg |
350kg |
400kg |
520kg |
