Pipe Diameter Reducing Machine

The pipe diameter reducing machine uses hydraulic technology to send the parts that need to be reduced, such as round steel and rebar, into special grinding tools for cold compression molding. The density of compressed steel can be greatly increased, thereby improving the compressive strength of the material.

Send Inquiry

Product Introduction

Machine Introduction

Application

Our fully automatic pipe diameter reducing machine is suitable for use in a variety of fields, such as steel processing plants, tunnel construction sites, bridge construction sites, road construction sites, housing renovations, construction sites, etc.

Advantage

Our Pipe Diameter Reducing Machine adopts an all-cast iron body, which greatly increases the service life of the body and is not easily damaged. High-strength hydraulic components are used to withstand high temperatures and provide accurate pressure indication, and are matched with a special plunger pump to reduce hydraulic oil wear. Using high-power copper core motor, it has strong power, improves efficiency and operates smoothly.

Contact now

Regarding the details of the pipe diameter reducing machine

1. The control panel adopts manual control buttons, which is simple and convenient, has fast diameter reduction speed and accurate size.

2. The fixing speed of the tie rod of the reducing machine is faster and the reducing effect is better.

3. The high-pressure hydraulic cylinder adopts the brand hydraulic cylinder design and has the characteristics of high clamping strength.

4. The motor adopts pure copper coil motor, which has stable operation and long service life.

5. The high-pressure pipe is designed to prevent oil leakage and cracking.

product parameters

Model	HT-MJ-20
Reduced diameter length	≤50cm
Hydraulic main pump	40mp
Lubrication pump	90w
Spindle center distance	120-240mm
Power	11kw
Hydraulic master cylinder	60t
Fastening cylinder	20t
Reducing range	12mm-30mm
Dimension	20001200860mm
Weight	1100kg

FAQ

Q: 1. Q: What's the MOQ:

A: A: 1 set

Q: 2. Q: Can the machine be customized?

A: A: As a professional manufacture, we can customize the machine according to your requirements, like capacity, material, color, voltage, logo, etc.

Q: 3. Q:What's the payment term?

A: A:We receive the T/T, Western union or Alibaba Trade Assurance Payment, ect.

Q: 4. Q:How to ship?

A: A:We have some long cooperation freight forwarder, they can help us ship the machine all over the world. Except sea, air, express, sea to the door is no problem.

Q: 5. Q: How to send the goods to customer?

A: A: The goods will be sent to you by sea, by air or by train. We can send the goods according to your need.

Q: 6. Q: Which port do you send the goods from?

A: A: Shanghai, Qingdao, Shenzhen or other port.

Q: 7.Q:How long is the warranty of the machine?

A: A:two years warranty

Q: 8.Q:how to buy this machine?

A: A:you could send us your company name and address ,then we draft proforma invoice ,you could pay to us via proforma invoice .

Q: 9.Q:What about the package?

A: A:Usually we will use the standard export wooden case.

Q: 10. Q:Are you manufacturer or trading company?

A: A:We are professional manufacturer of this machine,and we have manufactured this machine for more than 10 years.

Q: 11.Q:Do you need a supplier to provide transportation?

A: A：If need we ship help you,pls leave your details adress include zip code.

Q: 12.Q:Are there any requirements for power supply?

A: A: We can according customer's need to customized 110v/220v/380v/440v etc.

Q: Q: 13.What about Pre-sale service:

A: 13.A: Support voltage changing service as your demand; Support logo customizing ; Provide good solution for your project ; Testing and debugging before delivery ;
