Free Fall Metal Detector
High density thickened screw is adopted, with constant wear resistance, rapid reaction and more sensitive separation induction.
Product Introduction
Free Fall Metal Detector is a type of metal detector commonly used in the food industry to detect metal contaminants in free falling product streams.
As the product falls through the metal detector's aperture, the metal detector generates a magnetic field that is disrupted when metal is detected. This disruption triggers an alarm, halts the product flow, and signals the operator to remove the contaminated product. It is typically designed with a compact footprint, easy-to-clean surfaces, and high sensitivity to detect even the smallest metal particles. They are commonly used in applications such as dry powders, granules, and other free flowing products.
Free Fall Metal Detector is a kind of equipment used to detect metal objects. Its working principle is to generate electromagnetic fields and then detect any changes in the electromagnetic field caused by nearby metals. Metal detector can be used to detect all kinds of metal substances in food to achieve the purpose of food safety.
Feature of Free Fall Metal Detector:
Food grade 30 stainless steel body, four layers of material, high hardness, wear resistance, corrosion resistance, easy cleaning, safety and environmental protection, can be in direct contact with food.
Japan imported probe, high-precision separation of plastic, recycled materials, particles, powder doped with metal substances, rapid identification, can separate>=0.3 mm of metal debris.
It is made of wear-resistant imported nylon material carefully polished for 6 hours continuously, effectively avoiding the corrosion and wear of the channel caused by long-term injection.
Economic benefits of Free Fall Metal Detector
Free Fall Metal Detector at airports, stadiums, and other public places can help improve the overall customer experience by reducing wait times and providing reassurance to visitors that the environment is safe.
In industries where metal detection is required, such as food processing or mining, the use of metal detectors can help increase productivity by reducing downtime caused by equipment damage or contamination.
By identifying and removing metal contaminants from products during the production process, businesses can avoid costly product recalls and reputational damage.
Technical Parameter
|
Inner diameter of pipe |
30 |
50 |
70 |
100 |
150 |
|
|
detection accuracy |
Feø(mm) |
0.3 |
0.3 |
0.7 |
0.8 |
1.2 |
|
Susø(mm) |
0.5 |
0.5 |
1.0 |
1.2 |
1.5 |
|
|
detection accuracy |
Feø(mm) |
0.3 |
0.5 |
0.7 |
1.0 |
2.0 |
|
Susø(mm) |
1.0 |
1.2 |
1.5 |
2.0 |
3.5 |
|
|
Max capacity |
300-400kg/h |
700-800kg/h |
1000-1500kg/h |
2000-2500kg/h |
5000kg/h |
|
|
Alarm mode |
Automatic discharge |
|||||
|
Working Voltege |
220V/50-60Hz |
|||||
|
temperature |
10-50℃ |
|||||
|
Customized |
The inner diameter of the pipe can be customized as required |
|||||
|
Model |
HT-CQS02 |
|
Mouth diameter |
100mm |
|
Capacity |
500-2000kg/h |
|
Detection Sensitivity |
FE≥φ1.2mm |
|
Power |
220V, 60Hz |
|
Input Current |
80/160mA |
|
fuse |
2pcs 315 mA |
|
Environmental temperature |
-10~60℃ |
|
Protection level |
IP65 |
|
Compressed air |
4-8kg |
|
Air consumption |
0.4L per separation action |
|
Time of separation |
0.2-2.5s |
|
Adjustable detection accuracy |
0-10 grade |
Product Pictures
